PrintG6K Surface-Mounting Relay
Surface-Mounting Relay with the World's Smallest Mounting Area
- Subminiature model as small as 5.2 (H) × 6.5 (W) × 10 (L) mm is ideal for high-density mounting (G6K(U)-2F(-Y)).
- Low profile of 5.2 mm improves mounting efficiency (G6K(U)-2F(-Y)).
- Light weight of 0.7 g contributes to higher speed mounting.
- Surface mounting terminal models incorporate a unique terminal structure with high infrared irradiation efficiency which allows the terminal temperature to rise easily when mounting the IRS, thus ensuring excellent soldering.
- Ensures a dielectric strength of 1,500 VAC and conforms to FCC Part 68 (i.e., withstanding an impulse withstand voltage of 1,500 V for 10 × 160 νs).
- -Y models offer an impulse withstand voltage of 2,500 V for 2 × 10 νs (conforms to Telcordia specifications) by optimizing the distance between coil and contacts.
- Standard model conforms to UL/CSA standards, certified by BSI (EN60950).
- Models available with a 2.54-mm terminal pitch.
- Rated carry current: 2A.
Datasheet| Model | 2D/3D CAD | ECAD(Download symbol,FootPrint,3DCAD)
* External site (Ultra Librarian) opens in a new window. |
|---|---|---|
| G6K-2F | Download | Download |
| G6K-2F-Y | Download | Download |
| G6K-2G | Download | Download |
| G6K-2G-Y | Download | Download |
| G6K-2P | Download | Download |
| G6K-2P-Y | Download | Download |
| G6KU-2F-Y | Download | Download |
| G6KU-2G-Y | Download | Download |
| G6KU-2P-Y | Download | Download |
| Relay Function | Enclosure rating | Contact form | Model | Rated coil voltage | Minimum packing unit |
|---|---|---|---|---|---|
| Single-side stable | Fully sealed | DPDT (2c) | G6K-2F | 3 VDC | 50 pcs/tube (900 pcs/reel) |
| 4.5 VDC | |||||
| 5 VDC | |||||
| 12 VDC | |||||
| 24 VDC | |||||
| Highly insulated G6K-2F-Y | 3 VDC | ||||
| 4.5 VDC | |||||
| 5 VDC | |||||
| 12 VDC | |||||
| 24 VDC | |||||
| G6K-2G | 3 VDC | ||||
| 4.5 VDC | |||||
| 5 VDC | |||||
| 12 VDC | |||||
| 24 VDC | |||||
| Highly insulated G6K-2G-Y | 3 VDC | ||||
| 4.5 VDC | |||||
| 5 VDC | |||||
| 12 VDC | |||||
| 24 VDC | |||||
| Single-winding latching | Fully sealed | DPDT (2c) | Highly insulated G6KU-2F-Y | 3 VDC | |
| 4.5 VDC | |||||
| 5 VDC | |||||
| 12 VDC | |||||
| 24 VDC | |||||
| Highly insulated G6KU-2G-Y | 3 VDC | ||||
| 4.5 VDC | |||||
| 5 VDC | |||||
| 12 VDC | |||||
| 24 VDC |
●PCB Terminal Standard Models
| Relay Function | Enclosure rating | Contact form | Model | Rated coil voltage | Minimum packing unit |
|---|---|---|---|---|---|
| Single-side stable | Fully sealed | DPDT (2c) | G6K-2P | 3 VDC | 50 pcs/tube |
| 4.5 VDC | |||||
| 5 VDC | |||||
| 12 VDC | |||||
| 24 VDC | |||||
| Highly insulated G6K-2P-Y | 3 VDC | ||||
| 4.5 VDC | |||||
| 5 VDC | |||||
| 12 VDC | |||||
| 24 VDC | |||||
| Single-winding latching | Fully sealed | DPDT (2c) | Highly insulated G6KU-2P-Y | 3 VDC | |
| 4.5 VDC | |||||
| 5 VDC | |||||
| 12 VDC | |||||
| 24 VDC |
| Note: | 1. | When ordering, add the rated coil voltage to the model number. | |
| Example: G6K-2F |  | ||
| However, the notation of the coil voltage on the product case as well as on the packing will be marked as □□ VDC. | |||
| 2. | When ordering tape packing, add -TR" to the model number. Be sure since -TR" is not part of the relay model number, it is not marked on the relay case. When ordering tape packing, minimum order unit is 2 reels (900 pcs ✕ 2 = 1,800 pcs). | ||
| 3. | Surface mounting terminal (SMT) standard models are shipped in moisture-proof package. PCB terminal standard types do not require moisture proof packaging and therefore shipped in non-moisture-proof package. | ||
Single-side Stable Models
Item Rated voltage | Rated current (mA) | Coil resistance (Ω) | Must operate voltage (V) | Must release voltage (V) | Max. voltage (V) | Power consumption (mW) |
|---|---|---|---|---|---|---|
| % of rated voltage | ||||||
| 3 VDC | 33.0 | 91 | 80% max. | 10% min. | 150% | Approx. 100 |
| 4.5 VDC | 23.2 | 194 | ||||
| 5 VDC | 21.1 | 237 | ||||
| 12 VDC | 9.1 | 1,315 | ||||
| 24 VDC | 4.6 | 5,220 | ||||
| Note: | 1. | The rated current and coil resistance are measured at a coil temperature of 23°C with a tolerance of ±10%. |
| 2 | The operating characteristics are measured at a coil temperature of 23°C. | |
| 3. | The maximum voltage is the highest voltage that can be imposed on the relay coil instantaneously. |
Single-winding Latching Models(G6KU-2F-Y, G6KU-2G-Y, G6KU-2P-Y)
Item Rated voltage | Rated current (mA) | Coil resistance (Ω) | Must operate voltage (V) | Must release voltage (V) | Max. voltage (V) | Power consumption (mW) |
|---|---|---|---|---|---|---|
| % of rated voltage | ||||||
| 3 VDC | 33.0 | 91 | 75% max. | 75% max. | 150% | Approx. 100 |
| 4.5 VDC | 23.2 | 194 | ||||
| 5 VDC | 21.1 | 237 | ||||
| 12 VDC | 9.1 | 1,315 | ||||
| 24 VDC | 4.6 | 5,220 | ||||
| Note: | 1. | The rated current and coil resistance are measured at a coil temperature of 23°C with a tolerance of ±10%. |
| 2 | The operating characteristics are measured at a coil temperature of 23°C. | |
| 3. | The maximum voltage is the highest voltage that can be imposed on the relay coil instantaneously. |
Contact
| Resistive load | ||
|---|---|---|---|
| Contact type | Bifurcated crossbar | ||
| Contact material | Ag (Au-Alloy contact) | ||
| Rated load | 0.3 A at 125 VAC; 1 A at 30 VDC | ||
| Rated carry current | 2A | ||
| Max. switching voltage | 125 VAC, 60 VDC | ||
| Max. switching current | 1A |
Characteristics
| Single-side stable models (double-pole) | Single-winding latching model | ||||
|---|---|---|---|---|---|---|
| G6K-2F, G6K-2G, G6K-2P | G6K-2F-Y, G6K-2G-Y,G6K-2P-Y | G6KU-2F-Y, G6KU-2G-Y,G6KU-2P-Y | ||||
| Contact resistance *1 | 100 mΩ max. | |||||
| Operating (set) time | 3 ms max. | |||||
| Release (reset) time | 3 ms max. | |||||
| Minimum set/reset signal width | - | 10 ms | ||||
| Insulation resistance *2 | 1,000 MΩ min. (at 500 VDC) | |||||
| Dielectric strength | Between coil and contacts | 1,500 VAC, 50/60 Hz for 1 min | ||||
| Between contacts of different polarity | 1,000 VAC, 50/60 Hz for 1 min | |||||
| Between contacts of the same polarity | 750 VAC, 50/60 Hz for 1 min | |||||
| Impulse withstand voltage | Between coil and contacts | 1,500 V (10 × 160 νs) | 2,500 V (2 × 10 νs) 1,500 V (10 × 160 νs) | |||
| Between contacts of different polarity | 1,500 V (10 × 160 νs) | |||||
| Between contacts of the same polarity | ||||||
| Vibration resistance | Destruction | 10-55-10 Hz, 2.5 mm single amplitude (5 mm double amplitude) and 55 to 500 Hz, 300 m/s2 | ||||
| Malfunction: | 10-55-10 Hz, 1.65 mm single amplitude (3.3 mm double amplitude) and 55 to 500 Hz, 200 m/s2 | |||||
| Shock resistance | Destruction | 1,000 m/s2 | ||||
| Malfunction | 750 m/s2 | |||||
| Durability | Mechanical | 50,000,000 operations min. (at 36,000 operations/hour) | ||||
| Electrical | 100,000 operations min. (with a rated load at 1,800 operations/hour) | |||||
| Failure rate (P level) *3 | 10 µA at 10 mVDC | |||||
| Ambient operating temperature | -40 to 70°C (with no icing or condensation) | |||||
| Ambient operating humidity | 5% to 85% | |||||
| Weight | Approx. 0.7 g | |||||
| Note: | The above values are initial values. | |
| 1. | The contact resistance was measured with 10 mA at 1 VDC with a voltage-drop method. | |
| 2. | The insulation resistance was measured with a 500 VDC megohmmeter applied to the same parts as those used for checking the dielectric strength. | |
| 3. | This value was measured at a switching frequency of 120 operations/min and the criterion of contact resistance is 50 Ω. This value may vary depending on the switching frequency and operating environment. Always double-check relay suitability under actual operating conditions. | |
Single-side Stable G6K-2F | |||||
| Mounting Dimensions (TOP VIEW) Tolerance:±0.1mm | |||||
| Terminal Arrangement/ Internal Connections (TOP VIEW) Note: Check carefully the coil polarity of the Relay. | |||||
| |||||
| G6K-2G | |||||
| Mounting Dimensions (TOP VIEW) Tolerance:±0.1mm | |||||
| Terminal Arrangement/ Internal Connections (TOP VIEW) Note: Check carefully the coil polarity of the Relay. | |||||
| |||||
| G6K-2P | |||
| PCB Mounting Holes (Bottom VIEW) Tolerance:±0.1mm | |||
| Terminal Arrangement/ Internal Connections (Bottom VIEW) Note: Check carefully the coil polarity of the Relay. | |||
| |||
| G6K-2F-Y | |||||
| Mounting Dimensions (TOP VIEW) Tolerance:±0.1mm | |||||
| Terminal Arrangement/ Internal Connections (TOP VIEW) Note: Check carefully the coil polarity of the Relay. | |||||
| |||||
| G6K-2G-Y | |||||
| Mounting Dimensions (TOP VIEW) Tolerance:±0.1mm | |||||
| Terminal Arrangement/ Internal Connections (TOP VIEW) Note: Check carefully the coil polarity of the Relay. | |||||
| |||||
| G6K-2P-Y | |||
| PCB Mounting Holes (BOTTOM VIEW) Tolerance:±0.1mm | |||
| Terminal Arrangement/ Internal Connections (BOTTOM VIEW) Note: Check carefully the coil polarity of the Relay. | |||
| |||
| Single-winding Latching G6KU-2F-Y | |||||
| Mounting Dimensions (TOP VIEW) Tolerance:±0.1mm | |||||
| Terminal Arrangement/ Internal Connections (TOP VIEW) Note: Check carefully the coil polarity of the Relay. | |||||
| |||||
| G6KU-2G-Y | |||||
| Mounting Dimensions (TOP VIEW) Tolerance:±0.1mm | |||||
| Terminal Arrangement/ Internal Connections (TOP VIEW) Note: Check carefully the coil polarity of the Relay. | |||||
| |||||
| G6KU-2P-Y | |||
| PCB Mounting Holes (BOTTOM VIEW) Tolerance:±0.1mm | |||
| Terminal Arrangement/ Internal Connections (BOTTOM VIEW) Note: Check carefully the coil polarity of the Relay. | |||
| |||
Correct Use
●Long-term Continuously ON Contacts
Using the Relay in a circuit where the Relay will be ON continu- ously for long periods (without switching) can lead to unstable contacts because the heat generated by the coil itself will affect the insulation, causing a film to develop on the contact surfaces. We recommend using a latching relay (magnetic-holding relay) in this kind of circuit. If a single-side stable model must be used in this kind of circuit, we recommend using a fail-safe circuit design that provides protection against contact failure or coil burnout.
●Relay Handling
Use the Relay as soon as possible after opening the moisture- proof package. If the Relay is left for a long time after opening the moisture-proof package, the appearance may suffer and seal fail- ure may occur after the solder mounting process. To store the Relay after opening the moisture-proof package, place it into the original package and sealed the package with adhesive tape. When washing the product after soldering the Relay to a PCB, use a water-based solvent or alcohol-based solvent, and keep the solvent temperature to less than 40℃. Do not put the Relay in a cold cleaning bath immediately after soldering.
●Soldering
Soldering temperature: Approx. 250℃ (260℃ if the DWS method is used)
Soldering time: Approx. 5 s max. (approx. 2 s for the first time and approx. 3 s for the second time if the DWS method is used)
Be sure to adjust the level of the molten solder so that the solder will not overflow onto the PCB.
●Claw Securing Force During Automatic Mounting
During automatic insertion of Relays, make sure to set the secur- ing force of each claw to the following so that the Relays charac- teristics will be maintained.
●Environmental Conditions During Operation, Storage, and Transportation
Protect the Relay from direct sunlight and keep the Relay under normal temperature, humidity, and pressure. If the Relay is stored for a long time in an adverse environment with high temperature, high humidity, organic gases, or sulfide gases, sulfide or oxide films will form on the contact surfaces. These films may result in unstable contact, contact problems, or functional problems. Therefore, operate, store, or transport the product under specified environmental conditions.
●Latching Relay Mounting
·Make sure that the vibration or shock that is generated from other devices, such as relays in operation, on the same panel and imposed on the Latching Relay does not exceed the rated value, otherwise the Latching Relay that has been set may be reset or vice versa. The Latching Relay is reset before shipping. If exces- sive vibration or shock is imposed, however, the Latching Relay may be set accidentally. Be sure to apply a reset signal before use.
●Maximum Allowable Voltage
The maximum allowable voltage of the coil can be obtained from the coil temperature increase and the heat-resisting temperature of coil insulating sheath material. (Exceeding the heat-resisting temperature may result in burning or short-circuiting.) The maxi- mum allowable voltage also involves important restrictions which include the following:
Must not cause thermal changes in or deterioration of the insu- lating material.Must not cause damage to other control devices.
Must not cause any harmful effect on people.
Must not cause fire.
Therefore, be sure to use the maximum allowable voltage beyond the value specified in the catalog. As a rule, the rated voltage must be applied to the coil. A voltage exceeding the rated value, however, can be applied to the coil provided that the voltage is less than the maximum allowable volt- age. It must be noted that continuous voltage application to the coil will cause a coil temperature increase thus affecting charac- teristics such as electrical life and resulting in the deterioration of coil insulation.
●Coating
The Relay mounted on the PCB may be coated or washed but do not apply silicone coating or detergent containing silicone, other- wise the silicone coating or detergent may remain on the surface of the Relay.
●PCB Mounting
If two or more Relays are closely mounted with the long sides of the Relays facing each other and soldering is performed with infrared radiation, the solder may not be properly exposed to the infrared rays. Be sure to keep the proper distance between adja- cent Relays as shown below.
